The 325 series piston check valve is made of stainless steel, with PTFE gasket, short face to face, all position mounting, for chemical, pharmaceutical, petrochemical, hydraulic, water and compressed air industries.
| Specification | Value |
|---|---|
| DN inches NPS | 1/4'' |
| Option certificate 3.1 | Yes |
| Mounting direction | Horizontal |
| CE risk category | III Module H |
| Thread standard | ISO 228-1 |
| Tightness test standard | API 598. table 6 |
| Closure member material | Stainless steel ASTM A351 CF8M |
| Application | Industry |
| ATEX atmosphere | Group II Cat. 2G/2D |
| ATEX compatible | Yes |
| DN | DN8 - 1/4'' |
| Face to Face (mm) | 57.0 |
| Fluid | Acids |
| Gasket | PTFE |
| Body material | Stainless steel CF8M (1.4408) |
| PS (bar) | 50 |
| Connections | BSP FF |
| Seats | Stainless steel ASTM A351 CF8M |
| TS max (°C) | 200 |
| TS min (°C) | -20 |
| ATEX zone | 1 & 21. 2 & 22 |
| Warranty period | 2 years |
| CE | Yes |
| Obturator type | Piston |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| BSP FF Stainless steel CF8M (1.4408) Piston 1/4'' | 325002 | S1010815 |
€33.93
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) Piston 3/8'' | 325003 | S1010816 |
€33.93
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) Piston 1/2'' | 325004 | S1010817 |
€33.93
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) Piston 3/4'' | 325005 | S1010818 |
€43.47
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) Piston 1'' | 325006 | S1010819 |
€68.94
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) Piston 1''1/4 | 325007 | S1010820 |
€84.71
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) Piston 1''1/2 | 325008 | S1010821 |
€112.90
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) Piston 2'' | 325009 | S1010822 |
€165.93
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) Piston 2''1/2 | 325010 | S1010823 |
€349.40
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) Piston 3'' | 325011 | S1010824 |
€539.73
(excl. btw)
|
add to cart |
